Microwave Absorbers - Low Frequency

SB032-020 - Low Frequency Microwave Absorber

Wavexorb Low Frequency Absorbers are the thinnest and lightest formulations within our product range, and are formulated with unique magnetic fillers to provide high permeability in the lower frequency range of 500MHz to 3GHz. Designed to be applied to a metal surface or directly over a noisy circuit, each material is available in sheet and can be fabricated into application specific shapes.

NOTE: (...) = REQUIRED
[...] = OPTIONAL

(-02) 12" x 24" (305mm x 609mm)

(-03) 12" x 12" (305mm x 305mm)

[-A] Add -A for PSA backing

Examples:
SB032-020-03
SB032-020-02-A
Material: Silicone
Color: Dark Grey

Thickness: 0.020" (0.51 mm)

Adhesive: 0.002" (0.05 mm)

Temp Range: -60°F to 375°F
(-51°C to 190°C)

RoHS Compliant
Contains no halogens
