Microwave Absorbers - Narrowband

SN087-041 - Narrowband Microwave Absorber

Narrowband Absorbers (also known as Tuned Frequency or Resonant Frequency Absorbers) are single layer materials that absorb radiation at a specified frequency range, typically within +/- 10% of the target frequency. Narrowband Absorbers can be custom formulated to target a frequency by changing the formulation and thickness, are considerably thinner than other types of absorbers, and are the preferred choice for applications where broadband absorption is not required.

NOTE: (...) = REQUIRED
[...] = OPTIONAL

(-01) 24" x 24" (609mm x 609mm)

(-02) 12" x 24" (305mm x 609mm)

(-03) 12" x 12" (305mm x 305mm)

[-A] Add -A for PSA backing

Examples:
SN087-041-03
SN087-041-02-A
Material: Silicone
Color: Dark Grey

Thickness: 0.041" (1.04 mm)

Adhesive: 0.005" (0.13 mm)

Temp Range: -60°F to 375°F
(-51°C to 190°C)

RoHS Compliant
Contains no halogens
