Narrowband |
Narrowband Absorbers (also known as Tuned Frequency or Resonant Frequency Absorbers) are single layer materials that absorb radiation at a specified frequency range, typically within +/- 10% of the target frequency. Narrowband Absorbers can be custom formulated to target a frequency by changing the formulation and thickness, are considerably thinner than other types of absorbers, and are the preferred choice for applications where broadband absorption is not required.
| Part Number | Thickness | Material | Frequency (GHz) | -01 | -02 | -03 | Datasheet |
|---|---|---|---|---|---|---|---|
| SN071-175 | 0.175" (4.45mm) |
Silicone | 1.0 |  |
|
|
 |
| SN072-128 | 0.128" (3.25mm) |
Silicone | 2.0 | |
|
|
|
| SN073-095 | 0.095" (2.41mm) |
Silicone | 3.0 | |
|
|
|
| SN074-078 | 0.078" (1.98mm) |
Silicone | 4.0 | |
|
|
|
| SN075-081 | 0.081" (2.06mm) |
Silicone | 5.0 | |
|
|
|
| SN076-070 | 0.070" (1.78mm) |
Silicone | 6.0 | |
|
|
|
| SN077-062 | 0.062" (1.57mm) |
Silicone | 7.0 | |
|
|
|
| SN078-053 | 0.053" (1.35mm) |
Silicone | 8.0 | |
|
|
|
| SN079-072 | 0.072" (1.83mm) |
Silicone | 9.0 | |
|
|
|
| SN080-065 | 0.065" (1.65mm) |
Silicone | 10.0 | |
|
|
|
| SN081-060 | 0.060" (1.52mm) |
Silicone | 11.0 | |
|
|
|
| SN082-056 | 0.056" (1.42mm) |
Silicone | 12.0 | |
|
|
|
| SN083-051 | 0.051" (1.3mm) |
Silicone | 13.0 | |
|
|
|
| SN084-047 | 0.047" (1.19mm) |
Silicone | 14.0 | |
|
|
|
| SN085-045 | 0.045" (1.14mm) |
Silicone | 15.0 | |
|
|
|
| SN086-043 | 0.043" (1.09mm) |
Silicone | 16.0 | |
|
|
|
| SN087-041 | 0.041" (1.04mm) |
Silicone | 17.0 | |
|
|
|
| SN088-046 | 0.046" (1.17mm) |
Silicone | 18.0 | |
|
|
|
| SN089-140 | 0.140" (3.56mm) |
Silicone | 1.5 | |
|
|
|
| SN091-042 | 0.042" (1.07mm) |
Silicone | 24.0 | |
|
|
|
| SN092-110 | 0.110" (2.79mm) |
Silicone | 2.4 | |
|
|
|
| SN093-100 | 0.100" (2.54mm) |
Silicone | 3.8 | |
|
|
|
| SN094-020 | 0.020" (0.51mm) |
Silicone | 65.0 | |
|
|
|
| SN095-037 | 0.037" (0.94mm) |
Silicone | 28.0 | |
|
|
|
| SN096-034 | 0.034" (0.86mm) |
Silicone | 40.0 | |
|
|
|
| SN097-073 | 0.073" (1.85mm) |
Silicone | 5.8 | |
|
|
|
| SN100-036 | 0.036" (0.91mm) |
Silicone | 33.0 | |
|
|
|
| Sheet Size & Availability | |
| -01 | 24" x 24" (609mm x 609mm) |
| -02 | 12" x 24" (305mm x 609mm) |
| -03 | 12" x 12" (305mm x 305mm) |
|
Available in Specified Size |
 |
Not Available in Specified Size |
